This is an unused Uninterruptible Power Supply/Battery Backup unit. We have opened the box to check the batteries. Otherwise the UPS has never been used. The unit is covered by the BatteryUPSforLESS 1-year standard product warranty as well as our innovative 30-Day "Lemon" warranty.

Output

• Output Power Capacity 2100 Watts / 3000 VA
• Nominal Output Voltage 120V
• Waveform Type Sine wave
• Output Connections
  • (6) NEMA 5-15R (Standard 3-prong receptacles)
  • (2) NEMA 5-20R (3-prong 20Amp receptacles. Can accept standard 3-prong 15Amp plugs)

Input

• Nominal Input Voltage 120V
• Input Frequency 50/60 Hz +/- 5 Hz (auto sensing)
• Input Connections NEMA L5-30P (30 Amp Twistlock) Cord Length 8 feet (2.44 meters)
• Input voltage range for main operations 90 - 150V

Batteries & Runtime

• Included Battery Modules 2
• Typical recharge time 2.50 hour(s)
• Replacement Battery UBC44
• Extended Runtime Battery Modules (EBM's) Available (Model SURT192RMXLBP)

• Runtime Chart   (All times in minutes)	UPS Only	With 1 EBM	With 2 EBM's	With 3 EBM's	With 4 EBM's
  Runtime at full load (2100 Watts)	14	57	103	151	199
  Runtime at 75% load (1575 Watts)	21	79	141	206	272
  Runtime at half load (1050 Watts)	34	122	217	315	416
  Runtime at 25% load (525 Watts)	72	253	437	633	850
  Runtime at minimal load (210 Watts)	174	589	954	N/A	N/A

Communications & Management

• Interface Port(s) DB-9 RS-232,Smart-Slot
• Available SmartSlot™ Interface Quantity 1
• Emergency Power Off (EPO) Yes

Surge Protection and Filtering

• Surge energy rating 480 Joules
• Filtering Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

• Height 5.10 inches (130 mm)
• Width 17.00 inches (432 mm)
• Depth 26.00 inches (660 mm)
• Rack Height 3U
• Net Weight 120.00 lbs. (54.55 kg)
• Audible noise at 1 meter from surface of unit 55.00 dBA
• Online Thermal Dissipation 655.00 BTU/hr

Conformance

• Regulatory Approvals CSA,FCC Part 15 Class A,OSHPD,UL 1778
• Environmental Compliance RoHS 7b Exemption
